DERAY®-VT 220
Crosslinked Viton®
Fluoroelastomer heat shrink tubing suitable for use in electronic systems and components in military, aerospace, automotive, and industrial applications requiring outstanding heat and fluid resistance
Features and Benefits
- Flame retardant
- Flexible
- Highly abrasion resistant
- High withstand to corrosive fluids in extreme temperatures up to 220°C
- Shrink ratio: 2:1
- Continuous operating temperature: -55°C to 220°C
- Shrink temperature: 160°C
- UV Resistant
Standards
- DEF STAN 59-97 Type 4a
- BS G198 Part 3 Type 12A
- VG95343 Part 5 Type E
- PAN6480L
- GS 95008-3-3
- CNES approved and listed in Matrex database
- ECSS-Q-ST-70-02
Typical Applications
Bundling and strain relief of wire harnesses in high temperature applications and environments, excellently suitable for applications where severe chemical and thermal requirements are crucial, highly cut through resistant, commonly used for protection of cables against contamination by nearly all commercial hydraulic fluids, minerals and synthetic oils, widely used in hydraulic equipment, aircraft manufacture and ship building applications
Market/Applications
- Generation – Renewables – Wind
- Shipboard
- Single Wall
- OEM
- Industrial
- Automotive
- Utility
- Aerospace Defense
- Aerospace Defense
Ordering
Select a dimension which will shrink snugly over the component to be covered. If recovery is restricted the resultant wall thickness will be less than specified.
- Select options:
- Color: Black (BK)
- Please specify the product name, order number and options you require
- Order example: DERAY®-VT 220, 0375 or 3/8in, black
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
| Order Number | Expanded | Recovered | Delivery Units | |||||
| Internal Diameter (Min) D |
Internal Diameter (Max) d |
Wall Thickness (Nom) W |
Spool Lengths | |||||
| mm | in | mm | in | mm | in | m | ft | |
| 0125 | 3.20 | 1/8 | 1.60 | 0.063 | 0.80 | 0.031 | 50 | 164 |
| 0187 | 4.80 | 3/16 | 2.40 | 0.094 | 0.90 | 0.035 | 50 | 164 |
| 0250 | 6.40 | 1/4 | 3.20 | 0.126 | 0.90 | 0.035 | 50 | 164 |
| 0375 | 9.50 | 3/8 | 4.80 | 0.189 | 1.00 | 0.039 | 50 | 164 |
| 0500 | 12.70 | 1/2 | 6.40 | 0.252 | 1.20 | 0.047 | 30 | 98 |
| 0750 | 19.00 | 3/4 | 9.50 | 0.374 | 1.40 | 0.055 | 30 | 98 |
| 1000 | 25.40 | 1 | 12.70 | 0.500 | 1.80 | 0.071 | 30 | 98 |
| 1500 | 38.00 | 1 1/2 | 19.00 | 0.748 | 2.40 | 0.094 | 15 | 49 |
| 2000 | 50.80 | 2 | 25.40 | 1.000 | 2.80 | 0.110 | 15 | 49 |
| 3000 | 76.00 | 3 | 38.00 | 1.496 | 1.80 | 0.071 | 15 | 49 |
