CanuFlex PE-HB
Braided sleeve
Multipurpose economic braided sleeve for protection or bundling of cable, wires, pipes and hoses such as electrical harnesses, fluid pipes, air conditioning pipes.
Features and Benefits
- Very flexible
- Halogen free
- Highly expandable
- Lightweight but tough polyester monofilaments
- Push-back effect enables an easy application
- Resistant against chemicals and abrasion
- Self-extinguishing due to braided construction
- Continuous working temperature: -50°C to 150°C
Standards
- Automotive OEM specifications
Typical Applications
Cable bundling and protection, noise reduction, protection against abrasion
Market/Applications
- Industrial
- Automotive
Ordering
- Select options:
- Color: Black (BK), Orange (OE), Grey (GY)
- Please specify the product name, order number and options you require
- Order example: Canuflex PE-HB, 08, black
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
| Order Number | Nominal | Expanded | Delivery Units | |||||
| Internal Diameter (min) D | Internal Diameter (max) d | Spool lengths | Mini-Spool lengths | |||||
| mm | in | mm | in | m | ft | m | ft | |
| 03 | 2.0 | 0.079 | 6.0 | 0.236 | 500 | 1640 | 100 | 328 |
| 04 | 4.5 | 0.177 | 8.0 | 0.31 | 500 | 1640 | 100 | 328 |
| 05 | 5.0 | 0.197 | 10.0 | 0.394 | 500 | 1640 | 100 | 328 |
| 08 | 6.5 | 0.256 | 14.0 | 0.551 | 300 | 984 | 100 | 328 |
| 10 | 8.8 | 0.346 | 18.0 | 0.709 | 300 | 984 | 100 | 328 |
| 12 | 9.2 | 0.362 | 21.0 | 0.827 | 300 | 984 | 50 | 164 |
| 15 | 10.3 | 0.406 | 25.0 | 0.984 | 300 | 984 | 50 | 164 |
| 20 | 12.5 | 0.492 | 29.0 | 1.142 | 200 | 656 | 50 | 164 |
| 25 | 13.3 | 0.524 | 36.0 | 1.417 | 200 | 656 | 25 | 82 |
| 30 | 23.0 | 0.906 | 45.0 | 1.772 | 150 | 492 | 25 | 82 |
| 40 | 27.0 | 1.063 | 64.0 | 2.520 | 100 | 328 | 25 | 82 |
| 50 | 32.0 | 1.260 | 75.0 | 2.953 | 100 | 328 | 25 | 82 |
