DERAY®-VA 25
Modified crosslinked elastomer
The DERAY® – VA 25 is a diesel resistant elastomeric heat shrink tubing, for protecting cables, wire harnesses and brake lines in transportation and automotive applications where resistance to diesel, oil, hydraulic fluids and other chemicals is critical.
Features and Benefits
- Flame retardant
- Flexible
- High abrasion and cut resistance
- Long-term resistance to diesel, hydraulic fluids and chemicals
- Shrink ratio: 2:1
- Continuous operating temperature: -75°C to 150°C
- Shrink temperature: 150°C
Standards
- SAE-AMS-DTL-23053/16
- ASTM D2671
Typical Applications
Developed for rugged demands with view to high fuel, chemical and insulation requirements, suitable to use in rough environments where an optimum high-temperature fluid resistance, and long term heat resistance is required, protection for wire bundles, connectors, terminals and cable harnesses
Market/Applications
- Single Wall
- Industrial
- Automotive
Ordering
Select a dimension which will shrink snugly over the component to be covered. If recovery is restricted the resultant wall thickness will be less than specified.
- Select options:
- Color: Black (BK)
- Please specify the product name, order number and options you require
- Order example: DERAY®-VA 25 0750 or 3/4in, black
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
| Order Number | Expanded | Recovered | Delivery Units | |||||
| Internal Diameter (Min) D |
Internal Diameter (Max) d |
Wall Thickness (Nom) W |
Spool Lengths | |||||
| mm | in | mm | in | mm | in | m | ft | |
| 0125 | 3.2 | 1/8 | 1.6 | 0.063 | 0.80 | 0.031 | 50 | 164 |
| 0187 | 4.8 | 3/16 | 2.4 | 0.094 | 0.90 | 0.035 | 50 | 164 |
| 0250 | 6.4 | 1/4 | 3.2 | 0.126 | 1.00 | 0.039 | 50 | 164 |
| 0375 | 9.5 | 3/8 | 4.8 | 0.189 | 1.10 | 0.043 | 50 | 164 |
| 0500 | 12.7 | 1/2 | 6.4 | 0.252 | 1.30 | 0.051 | 30 | 98 |
| 0750 | 19.0 | 3/4 | 9.5 | 0.374 | 1.50 | 0.059 | 30 | 98 |
| 1000 | 25.4 | 1 | 12.7 | 0.500 | 1.90 | 0.075 | 30 | 98 |
| 1500 | 38.0 | 1 1/2 | 19.0 | 0.748 | 2.50 | 0.098 | 15 | 49 |
| 2000* | 51.0 | 2 | 25.4 | 1.000 | 3.10 | 0.122 | – | – |
| 3000* | 76.0 | 3 | 38.0 | 1.496 | 3.30 | 0.130 | – | – |
*Sizes 2in, 3in are MOQ items
