CFSP / CRFP – EMEA
Fibre optic splice protector
CFSP / CRFP – EMEA is a specially designed crosslinked polyolefin tubing system, with meltable liner, providing strength and protection to optical fibre splices.
Features and Benefits
- Single holed (preshrunk) ends eliminate improper fibre threading
- Single fiber and ribbon fibre splice protector available
- Smooth, deburred stainless steel reinforcing member ends decrease the risk of fibre damage during installation
- Suitable for use with all fusion splicers
- Extended liner length prevents contact between the fibre and the backbone
- Clear sleeve design permits easy centering of splice before heating
- Shrink ratio: 3:1
- Continuous operating temperature: -40°C to 70°C
- Shrink temperature: 90°C
Standards
- GR-1380 compliant
- Bellcore SR-4301 Level 2
- British Telecom RC85-92A
Typical Applications
Protection of fusion splices in optical networks
CFSP Single
CRFP Ribbon
Market/Applications
- OEM
- Industrial
- Communications Cable Splice & Protection
Ordering
- Select a dimension which will shrink snugly over the component to be covered. If recovery is restricted the resultant wall thickness will be less than specified.
- Select options:
- Color: Clear (CL)
- Please specify the product name, order number and options you require
- Order example: CFSP-12-45, clear, 2.000 pcs.
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
CFSP Single
CFSP-9-4545.01.771.40.060.760.031100
| Order Number | Expanded | Recovered | Delivery Units | |||||
| Internal Diameter (Min) D |
Internal Diameter (Max) d |
Wall Thickness (Nom) W |
Number of Splices | Pieces per Bag | ||||
| mm | in | mm | in | mm | in | |||
| Standard | ||||||||
| CFSP-12-61 | 61.0 | 2.402 | 1.5 | 0.059 | 1.20 | 0.047 | 1 | 100 |
| CFSP-12-45 | 45.0 | 1.772 | 1.5 | 0.059 | 1.20 | 0.047 | 1 | 100 |
| CFSP-12-23 | 23.0 | 0.906 | 1.5 | 0.059 | 1.20 | 0.047 | 1 | 100 |
| Thin | ||||||||
Support rod for CFSP is made from stainless steel / Support rod for CRFP is made from ceramic
CRFP Ribbon
| Order Number | Expanded | Recovered | Delivery Units | |||||
| Internal Diameter (Min) D |
Internal Diameter (Max) D |
Wall Thickness (Nom) W |
Number of Splices | Pieces per Bag | ||||
| mm | in | mm | in | mm | in | |||
| CRFP-12 | 40.0 | 1.575 | 3.0 | 0.118 | 1.20 | 0.05 | 12 | 50 |
