DERAY®-PSP-D
Heat shrink system
The DERAY®-PSP-D is a heat shrink system with infrared heating elements designed to process adhesive lined heat shrink tubes onto splice joints, especially for twisted cables, in batches of 5.
Features and Benefits
- Robust and durable IR ceramic heating elements
- Centering tool supports tubing positioning
- Process cost improvement by processing 5 splices per cycle
- Cooling system: Compressed air
- Pneumatic protection cover ensures safe process
- Adjustable parameters: Shrink and cooling time, temperature control through Siemens CPU
- Password protected programming mode
- Selection of system language: English, German, Romanian (others on demand)
- CE and RoHs conformity
Applications
Parallel splices
Operation
The DERAY®-PSP-D is equipped with a 5-splice holder. Position marks facilitate the insertion and positioning the splice and heat shrink tubing. After the safety hood is locked, the two IR heating elements move forward to the working position. After the shrinking procedure, the heating elements move back to the home position and cooling nozzles begin to cool down the completed application. The cooling system helps to ensure that the inserted cables are quickly moving to the next procedural step and helps to harden any leaking adhesive rapidly. At the end of the shrinking process, the safety hood unlocks, and the 5-way splice holder is opened.
Order Information
DERAY®-PSP-D
Heat Shrink Products & Sizes
DERAY®-SpliceMelt Sizes 1 and 2, length max. 50 mm
For other products and sizes contact DSG-Canusa Application Engineering
Scope of Delivery
- Shrink equipment
- Operating manual: English, German, Romanian (others on demand)
Accessories
- Calibration sensor
Market/Applications
- Dual Wall
- Single Wall
- OEM
- Splice Sealing Solutions
- Transit
- Automotive
- Marine
- Aerospace Defense
- Application Equipment
- Waterblocking
| Properties | |
| Electrical connection | 1/N/PE AC 230 V 50-60 Hz |
| Electrical power consumption | 800 watt |
| Rated current | 8 A |
| Electrical fuse protection at the owner | 16 A |
| Degree of protection | IP 20 |
| Pneumatic connection | 5 – 8 bar (72 psi – 116 psi) |
| Shrink temperature at the IR heater | 200 °C – 550 °C (392°F – 1022°F) |
| Distance of IR-ceramic heating elements | 30mm – 50mm (1.18 in – 2.0 in) |
| Ambient temperature | 10°C – 45°C (50°F – 113°F) |
| Sound pressure level | approx. 60 dB(A) |
| Dimensions and weight | |
| Shrink equipment | w 600 x h 850 x d 900 mm (w 23.6 x h 33.5 x d 40 in) 40 kg (88.2 lbs) |
