DERAY®-IHKT
Thin wall adhesive lined polyolefin
Flexible heat shrink tubing with a temperature resistant polyamide adhesive inner lining; ideal for protecting components in a wide range of electrical and mechanical applications where adhesion to connector and metal substrates is critical.
Features and Benefits
- High shrink ratio allows for coverage of irregularly shaped connectors and components
- Flame retardant
- Specially designed polyamide adhesive protects components at higher temperatures
- Superior sealing against water and other contaminants
- Inner adhesive bonds to plastics, rubbers and metals
- Shrink ratio: 4:1
- Continuous operating temperature: -55°C to 125°C
- Shrink temperature: 100°C min.
Standards
- VG 95343 Part 12 Type D
- Approved to major automotive OEM specifications
Typical Applications
Retrofit protection of connectors, repair of damaged wire harnesses, moisture sealing and strain relief at connectors and terminals
Market/Applications
- Industrial
- Automotive
Ordering
Select a dimension which will shrink snugly over the application to be covered. If recovery is restricted the resultant wall thickness will be less than specified.
- Select options:
- Color: Black (BK)
- Please specify the product name, order number and options you require
- Example: DERAY®-IHKT, 0630 or 16.0/4.0, black
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
| Order Number | Expanded | Recovered | Delivery Units | ||||||
| Internal Diameter (Min) D |
Internal Diameter (Max) d |
Total Wall Thickness (Nom) W |
Spool | Lengths | |||||
| mm | in | mm | in | mm | in | m | ft | 1.22m / 48in | |
| 0157 | 4.0 | 0.157 | 1.0 | 0.039 | 1.00 | 0.039 | 300 | 984 | 25 |
| 0315 | 8.0 | 0.315 | 2.0 | 0.079 | 1.20 | 0.047 | 150 | 492 | 10 |
| 0472 | 12.0 | 0.472 | 3.0 | 0.118 | 1.40 | 0.055 | 100 | 328 | 10 |
| 0630 | 16.0 | 0.630 | 4.0 | 0.157 | 1.70 | 0.067 | 50 | 164 | 10 |
| 0945 | 24.0 | 0.945 | 6.0 | 0.236 | 2.10 | 0.083 | 50 | 164 | 10 |
| 1260 | 32.0 | 1.260 | 8.0 | 0.315 | 2.40 | 0.094 | 50 | 164 | 10 |
| 2047 | 52.0 | 2.047 | 13.0 | 0.512 | 2.40 | 0.094 | 30 | 98 | 10 |
