CFSP / CRFP – Americas
Fiber optic splice protector
CFSP / CRFP – Americas is a specially designed cross-linked polyolefin tubing system, with meltable liner, providing strength and protection to optical fiber splices.
Features and Benefits
- Single fiber and ribbon fiber splice protector available
- Single holed (preshrunk) ends eliminate improper fiber threading
- Smooth, de-burred stainless steel reinforcing member ends decrease the risk of fiber damage during installation
- Extended liner length prevents contact between the fiber and the backbone
- Clear sleeve design permits easy centering of splice before heating
- Continuous operating temperature: -40°C to 60°C
- Shrink temperature: 90°C
Standards
- GR-1380 compliant
Typical Applications
Protection of fusion splices in optical networks
Packaging
- CFSP: 100 pieces per bag
- CRFP: 50 pieces per bag
Please contact your Customer Service Representative for information on custom colors, sizes, lengths and material data sheet.
CFSP Single Fiber Protectors
CRFP Ribbon Fiber Protector
*Support rod for CFSP is made from stainless steel
**Support rod for CFRP is made from ceramic
Market/Applications
- OEM
- Industrial
- Communications Cable Splice & Protection
Ordering
Select a dimension which will shrink snugly over the component to be covered. If recovery is restricted the resultant wall thickness will be less than specified.
- Select options:
- CFSP Single Fiber Protectors or CFRP Ribbon Fiber Protectors
- Order Example: CFSP-12-61, 100 pieces per bag
CFSP Single Fiber Protectors
| Order Number | Nominal Sleeve Length | Inside Diameter of Inner Liner (Min) | Nominal Support Rod Diameter* | Packaging | Number of Splices | |||
| mm | in | mm | in | mm | in | Pieces per bag | ||
| CFSP-12-61 | 61.0 | 2.40 | 1.5 | 0.06 | 1.2 | 0.05 | 100 | 1 |
| CFSP-12-45 | 45.0 | 1.77 | 1.5 | 0.06 | 1.2 | 0.05 | 100 | 1 |
| CFSP-12-23 | 23.0 | 0.90 | 1.5 | 0.06 | 1.2 | 0.05 | 100 | 1 |
CRFP Ribbon Fiber Protector
| Order Number | Nominal Sleeve Length | Inside Diameter of Inner Liner (Min) | Nominal Support Rod Diameter** | Packaging | Number of Splices | |||
| mm | in | mm | in | mm | in | Pieces per bag | ||
| CRFP-12 | 40.0 | 1.57 | 3.0 | 0.12 | 1.8 | 0.07 | 50 | 12 |
*Support rod for CFSP is made from stainless steel
**Support rod for CFRP is made from ceramic
